Special Property SMC Material

Product characteristics ：

1.High oxygen index.

2. low density .

3. corrosion preventive.

4. High intensity.

Special properties SMC materials

Recommended application：

The design of SMC materials is very good. Some properties, such as flame retardancy, density, corrosion resistance and higher strength, can be designed for specific applications.

Typical data ：

Physical property	Test Standards	Units	Typical grades and data
Physical property	Test Standards	Units	FSD-S11	FSD-S12	FSD-S20	FSD-S25 DMD	FSD-S30 NFS
Test standard	GB/T 15568-2008	%	25%±2	21%±2	47%±2	27%±2	30%±2
Molding temperature	-	℃	145 - 155	145 - 155	145 - 155	145 - 155	145 - 155
Shrink rate	GB/T 15568-2008	%	≤0.15	≤0.02	≤0.15	≤0.15	≤0.15
Density	GB/T 1463-2005	g/cm3	1.8~1.9	1.8~1.9	1.8~1.9	1.4~1.5	1.8~1.9
Stretch Strength	GB/T 1447-2005	Mpa	≥45	≥30	≥140	≥50	≥75
Bend Strength	GB/T 1449-2005	Mpa	≥130	≥130	≥250	≥155	≥170
Bend Modulus	GB/T 1449-2005	Gpa	≥8	≥8	≥10	≥9	≥9
Impact Strength	GB/T 1451-2005	Mpa	≥40	≥35	≥140	≥55	≥70
Oxygen Index	GB/T 8924-2005	GB/T 8924-2005	≥45	≥80	-	-	-

Attention：

1. We can design the color as customers request.

2. We suggest the store environment below 25℃，shade place ,60days .

Property	Fiberglass content	Stretch strength	Bend strength	Impact strength	Shrink rate	Oxygen index	Flame resistant grade	Dielectric strength	Arc resistance
Test standard	GB/T 15568-2008	GB/T 1447-2005	GB/T 1449-2005	GB/T 1451-2005	GB/T 15568-2008	GB/T 8924-2005	UL-94	GB/T 1408-2006	GB/T 1411-2002
Unit	%	Map	Map	KJ/㎡	%	%	Grade	KV/mm	S
B-01	20%±2	≥45	≥135	≥40	≤0.15	≥28	V1	≥12	≥180
B-02	25%±2	≥55	≥155	≥50	≤0.15	≥28	V1	≥12	≥180
D-01	20%±2	≥45	≥135	≥40	≤0.15	≥32	V0	≥12	≥180
D-02	24%±2	≥50	≥155	≥50	≤0.15	≥32	V0	≥12	≥180
D-03	26%±2	≥60	≥160	≥55	≤0.15	≥32	V0	≥12	≥180
Thermal deformation temperature	GB/T 1634.1-2004	℃	≥200	≥200	≥200	≥200
