Architecture Application

Product advantages :

1. good dimensional stability.

2. Good strength and toughness.

3. Good weather resistance.

4. Convenient installation.
Availability:

 SMC materials for architecture


Recommended application:

It is recommended for the production of Nestle plate, or other building materials, etc.


Typical data :

Physical property



Test Standards



Units



Typical grades and data

FSD-A05

FSD-A06

Fiberglass content


GB/T

15568-2008

%

25%±2

28%±2

Molding temperature


-

145 - 155

145 - 155

Shrink  rate


GB/T

15568-2008

%

≤0.15

≤0.15

Density


GB/T

1463-2005

g/cm3

1.8~1.9

1.8~1.9

Stretch  Strength


GB/T

1447-2005

Mpa

≥55

≥75

Bend Strength


GB/T

1449-2005

Mpa

≥155

≥170

Bend  Modulus


GB/T

1449-2005

Gpa

≥9

≥9

Impact Strength


GB/T

1451-2005

Mpa

≥50

≥70



Attention:

1. We can design the color as customers request.

2. We suggest the store environment below 25℃,shade place ,60days .


Property

Fiberglass content

Stretch strength

Bend strength

Impact strength

Shrink rate

Oxygen index

Flame resistant grade

Dielectric strength

Arc  Resistance


Test standard

GB/T

15568-2008

GB/T

1447-2005

GB/T

1449-2005

GB/T

1451-2005

GB/T

15568-2008

GB/T

8924-2005

UL-94

GB/T

1408-2006

GB/T

1411-2002

unit

%

Map

Map

KJ/㎡

%

%

Grade

KV/mm

S

B-01

20%±2

≥45

≥135

≥40

≤0.15

≥28

V1

≥12

≥180

B-02

25%±2

≥55

≥155

≥50

≤0.15

≥28

V1

≥12

≥180

D-01

20%±2

≥45

≥135

≥40

≤0.15

≥32

V0

≥12

≥180

D-02

24%±2

≥50

≥155

≥50

≤0.15

≥32

V0

≥12

≥180

D-03

26%±2

≥60

≥160

≥55

≤0.15

≥32

V0

≥12

≥180

Thermal deformation temperature


GB/T

1634.1-2004

≥200

≥200

≥200

≥200
